2부에 이어서, 3부를 시작 합니다.
8. 이제 생성된 코드를 리팩토링 해달라고 부탁 합니다.
from enum import Enum
class Command(Enum):
PUSH = 'PUSH'
POP = 'POP'
ADD = 'ADD'
SUB = 'SUB'
MUL = 'MUL'
DIV = 'DIV'
MOD = 'MOD'
DUP = 'DUP'
SWAP = 'SWAP'
JMP = 'JMP'
JG = 'JG'
JL = 'JL'
JZ = 'JZ'
JNZ = 'JNZ'
CMP = 'CMP'
MOV = 'MOV'
NOP = 'NOP'
HALT = 'HALT'
class StackMachine:
"""
PUSH <value>: Push a value onto the stack. e.g., PUSH 10
POP: Remove and return the top value from the stack.
ADD: Remove the top two values from the stack, calculate their sum, and push the result onto the stack.
SUB: Remove the top two values from the stack, calculate their difference, and push the result onto the stack.
MUL: Remove the top two values from the stack, calculate their product, and push the result onto the stack.
DIV: Remove the top two values from the stack, calculate their division, and push the result onto the stack.
MOD: Remove the top two values from the stack, calculate their remainder, and push the result onto the stack.
DUP: Copy the top value from the stack and push it onto the stack.
SWAP: Swap the top two values on the stack.
JMP <label>: Move program execution to the given label. e.g., JMP LOOP
JG <label>: If the top value on the stack is greater than 0, move program execution to the given label.
JL <label>: If the top value on the stack is less than 0, move program execution to the given label.
JZ <label>: If the top value on the stack is 0, move program execution to the given label.
JNZ <label>: If the top value on the stack is not 0, move program execution to the given label.
CMP: Compare the top two values on the stack and push the result onto the stack.
(-1: First value is smaller, 0: Both values are equal, 1: First value is larger)
MOV <register>: Move the top value from the stack to the specified register (AX, BX, CX, or DX).
NOP: Perform no operation. This command is ignored in the program.
HALT: Stop program execution.
"""
def __init__(self):
self.stack = []
self.program = []
self.labels = {}
self.registers = {'AX': 0, 'BX': 0, 'CX': 0, 'DX': 0}
self.instruction_pointer = 0
def load_program(self, program):
self.program = program
self.labels = {line[:-1]: i for i, line in enumerate(program) if line.endswith(':')}
def parse_command(self, command_string):
command, *args = command_string.split()
if command not in Command.__members__:
raise ValueError(f"Invalid command: {command}")
return Command[command], args
def execute_command(self, command, args):
if command == Command.PUSH:
value = int(args[0]) if 'X' not in args[0] else self.registers[args[0]]
self.stack.append(value)
elif command == Command.POP:
self.stack.pop()
elif command == Command.ADD:
self.stack.append(self.stack.pop() + self.stack.pop())
elif command == Command.SUB:
b, a = self.stack.pop(), self.stack.pop()
self.stack.append(a - b)
elif command == Command.MUL:
self.stack.append(self.stack.pop() * self.stack.pop())
elif command == Command.DIV:
b, a = self.stack.pop(), self.stack.pop()
self.stack.append(a // b)
elif command == Command.MOD:
b, a = self.stack.pop(), self.stack.pop()
self.stack.append(a % b)
elif command == Command.DUP:
self.stack.append(self.stack[-1])
elif command == Command.SWAP:
self.stack[-1], self.stack[-2] = self.stack[-2], self.stack[-1]
elif command == Command.JMP:
self.instruction_pointer = self.labels[args[0]]
return
elif command == Command.JG:
if self.stack.pop() == 1:
self.instruction_pointer = self.labels[args[0]]
return
elif command == Command.JL:
if self.stack.pop() == -1:
self.instruction_pointer = self.labels[args[0]]
return
elif command == Command.JZ:
if self.stack.pop() == 0:
self.instruction_pointer = self.labels[args[0]]
return
elif command == Command.JNZ:
if self.stack.pop() != 0:
self.instruction_pointer = self.labels[args[0]]
return
elif command == Command.CMP:
b, a = self.stack.pop(), self.stack.pop()
self.stack.append((a > b) - (a < b))
elif command == Command.MOV:
self.registers[args[0]] = self.stack[-1]
elif command == Command.NOP:
pass
elif command == Command.HALT:
return
else:
raise ValueError(f"Unknown command: {command}")
self.instruction_pointer += 1
def run(self):
for _ in range(20000):
if self.instruction_pointer >= len(self.program):
break
command_string = self.program[self.instruction_pointer]
command, args = self.parse_command(command_string)
self.execute_command(command, args)
생성된 코드를 돌려보면, 역시 안됩니다.
디버깅 하면, Label 처리가 안되었을 알 수 있습니다.
9. Label 처리를 위한 코드를 손으로 추가 하여 수정 합니다.
from enum import Enum
class Command(Enum):
PUSH = 'PUSH'
POP = 'POP'
ADD = 'ADD'
SUB = 'SUB'
MUL = 'MUL'
DIV = 'DIV'
MOD = 'MOD'
DUP = 'DUP'
SWAP = 'SWAP'
JMP = 'JMP'
JG = 'JG'
JL = 'JL'
JZ = 'JZ'
JNZ = 'JNZ'
CMP = 'CMP'
MOV = 'MOV'
NOP = 'NOP'
HALT = 'HALT'
LABEL = 'LABEL'
class StackMachine:
"""
PUSH <value>: Push a value onto the stack. e.g., PUSH 10
POP: Remove and return the top value from the stack.
ADD: Remove the top two values from the stack, calculate their sum, and push the result onto the stack.
SUB: Remove the top two values from the stack, calculate their difference, and push the result onto the stack.
MUL: Remove the top two values from the stack, calculate their product, and push the result onto the stack.
DIV: Remove the top two values from the stack, calculate their division, and push the result onto the stack.
MOD: Remove the top two values from the stack, calculate their remainder, and push the result onto the stack.
DUP: Copy the top value from the stack and push it onto the stack.
SWAP: Swap the top two values on the stack.
JMP <label>: Move program execution to the given label. e.g., JMP LOOP
JG <label>: If the top value on the stack is greater than 0, move program execution to the given label.
JL <label>: If the top value on the stack is less than 0, move program execution to the given label.
JZ <label>: If the top value on the stack is 0, move program execution to the given label.
JNZ <label>: If the top value on the stack is not 0, move program execution to the given label.
CMP: Compare the top two values on the stack and push the result onto the stack.
(-1: First value is smaller, 0: Both values are equal, 1: First value is larger)
MOV <register>: Move the top value from the stack to the specified register (AX, BX, CX, or DX).
NOP: Perform no operation. This command is ignored in the program.
HALT: Stop program execution.
"""
def __init__(self):
self.stack = []
self.program = []
self.labels = {}
self.registers = {'AX': 0, 'BX': 0, 'CX': 0, 'DX': 0}
self.instruction_pointer = 0
def load_program(self, program):
self.program = program
self.labels = {line[:-1]: i for i, line in enumerate(program) if line.endswith(':')}
def parse_command(self, command_string):
command, *args = command_string.split()
if command not in Command.__members__:
if ':' in command:
return Command['LABEL'], args
else:
raise ValueError(f"Unknown command: {command}")
return Command[command], args
def execute_command(self, command, args):
if command == Command.PUSH:
value = int(args[0]) if 'X' not in args[0] else self.registers[args[0]]
self.stack.append(value)
elif command == Command.POP:
self.stack.pop()
elif command == Command.ADD:
self.stack.append(self.stack.pop() + self.stack.pop())
elif command == Command.SUB:
b, a = self.stack.pop(), self.stack.pop()
self.stack.append(a - b)
elif command == Command.MUL:
self.stack.append(self.stack.pop() * self.stack.pop())
elif command == Command.DIV:
b, a = self.stack.pop(), self.stack.pop()
self.stack.append(a // b)
elif command == Command.MOD:
b, a = self.stack.pop(), self.stack.pop()
self.stack.append(a % b)
elif command == Command.DUP:
self.stack.append(self.stack[-1])
elif command == Command.SWAP:
self.stack[-1], self.stack[-2] = self.stack[-2], self.stack[-1]
elif command == Command.JMP:
self.instruction_pointer = self.labels[args[0]]
return
elif command == Command.JG:
if self.stack.pop() == 1:
self.instruction_pointer = self.labels[args[0]]
return
elif command == Command.JL:
if self.stack.pop() == -1:
self.instruction_pointer = self.labels[args[0]]
return
elif command == Command.JZ:
if self.stack.pop() == 0:
self.instruction_pointer = self.labels[args[0]]
return
elif command == Command.JNZ:
if self.stack.pop() != 0:
self.instruction_pointer = self.labels[args[0]]
return
elif command == Command.CMP:
b, a = self.stack.pop(), self.stack.pop()
self.stack.append((a > b) - (a < b))
elif command == Command.MOV:
self.registers[args[0]] = self.stack[-1]
elif command == Command.NOP:
pass
elif command == Command.HALT:
return
elif command == Command.LABEL:
pass
else:
raise ValueError(f"Unknown command: {command}")
self.instruction_pointer += 1
def run(self):
for _ in range(20000):
if self.instruction_pointer >= len(self.program):
break
command_string = self.program[self.instruction_pointer]
command, args = self.parse_command(command_string)
self.execute_command(command, args)
10. execute_command() 함수 안의 수 많은 if - else 조합을 없애기 위해서 약간 코드를 고칩니다.
def command_push(self, args):
value = int(args[0]) if 'X' not in args[0] else self.registers[args[0]]
self.stack.append(value)
def command_pop(self, args):
self.stack.pop()
위와 같이 함수를 2개 추가하고, 코드를 약간 고쳐 줍니다.
11. 수정 된 코드를 넣고, 리팩토링을 부탁합니다.
from enum import Enum
class Command(Enum):
PUSH = 'PUSH'
POP = 'POP'
ADD = 'ADD'
SUB = 'SUB'
MUL = 'MUL'
DIV = 'DIV'
MOD = 'MOD'
DUP = 'DUP'
SWAP = 'SWAP'
JMP = 'JMP'
JG = 'JG'
JL = 'JL'
JZ = 'JZ'
JNZ = 'JNZ'
CMP = 'CMP'
MOV = 'MOV'
NOP = 'NOP'
HALT = 'HALT'
LABEL = 'LABEL'
class StackMachine:
"""
PUSH <value>: Push a value onto the stack. e.g., PUSH 10
POP: Remove and return the top value from the stack.
ADD: Remove the top two values from the stack, calculate their sum, and push the result onto the stack.
SUB: Remove the top two values from the stack, calculate their difference, and push the result onto the stack.
MUL: Remove the top two values from the stack, calculate their product, and push the result onto the stack.
DIV: Remove the top two values from the stack, calculate their division, and push the result onto the stack.
MOD: Remove the top two values from the stack, calculate their remainder, and push the result onto the stack.
DUP: Copy the top value from the stack and push it onto the stack.
SWAP: Swap the top two values on the stack.
JMP <label>: Move program execution to the given label. e.g., JMP LOOP
JG <label>: If the top value on the stack is greater than 0, move program execution to the given label.
JL <label>: If the top value on the stack is less than 0, move program execution to the given label.
JZ <label>: If the top value on the stack is 0, move program execution to the given label.
JNZ <label>: If the top value on the stack is not 0, move program execution to the given label.
CMP: Compare the top two values on the stack and push the result onto the stack.
(-1: First value is smaller, 0: Both values are equal, 1: First value is larger)
MOV <register>: Move the top value from the stack to the specified register (AX, BX, CX, or DX).
NOP: Perform no operation. This command is ignored in the program.
HALT: Stop program execution.
"""
def __init__(self):
self.stack = []
self.program = []
self.labels = {}
self.registers = {'AX': 0, 'BX': 0, 'CX': 0, 'DX': 0}
self.command_list = {}
self.instruction_pointer = 0
self._init_command_list()
def _init_command_list(self):
self.command_list[Command.PUSH] = self.command_push
self.command_list[Command.POP] = self.command_pop
self.command_list[Command.ADD] = self.command_add
self.command_list[Command.SUB] = self.command_sub
self.command_list[Command.MUL] = self.command_mul
self.command_list[Command.DIV] = self.command_div
self.command_list[Command.MOD] = self.command_mod
self.command_list[Command.DUP] = self.command_dup
self.command_list[Command.SWAP] = self.command_swap
self.command_list[Command.JMP] = self.command_jmp
self.command_list[Command.JG] = self.command_jg
self.command_list[Command.JL] = self.command_jl
self.command_list[Command.JZ] = self.command_jz
self.command_list[Command.JNZ] = self.command_jnz
self.command_list[Command.CMP] = self.command_cmp
self.command_list[Command.MOV] = self.command_mov
self.command_list[Command.NOP] = self.command_nop
self.command_list[Command.HALT] = self.command_halt
self.command_list[Command.LABEL] = self.command_label
def load_program(self, program):
self.program = program
self.labels = {line[:-1]: i for i, line in enumerate(program) if line.endswith(':')}
def parse_command(self, command_string):
command, *args = command_string.split()
if command not in Command.__members__:
if ':' in command:
return Command['LABEL'], args
else:
raise ValueError(f"Unknown command: {command}")
return Command[command], args
def execute_command(self, command, args):
if command in self.command_list:
self.command_list[command](args)
else:
raise ValueError(f"Unknown command: {command}")
self.instruction_pointer += 1
def command_push(self, args):
value = int(args[0]) if 'X' not in args[0] else self.registers[args[0]]
self.stack.append(value)
def command_pop(self, args):
self.stack.pop()
def command_add(self, args):
self.stack.append(self.stack.pop() + self.stack.pop())
def command_sub(self, args):
b, a = self.stack.pop(), self.stack.pop()
self.stack.append(a - b)
def command_mul(self, args):
self.stack.append(self.stack.pop() * self.stack.pop())
def command_div(self, args):
b, a = self.stack.pop(), self.stack.pop()
self.stack.append(a // b)
def command_mod(self, args):
b, a = self.stack.pop(), self.stack.pop()
self.stack.append(a % b)
def command_dup(self, args):
self.stack.append(self.stack[-1])
def command_swap(self, args):
self.stack[-1], self.stack[-2] = self.stack[-2], self.stack[-1]
def command_jmp(self, args):
self.instruction_pointer = self.labels[args[0]]
def command_jg(self, args):
if self.stack.pop() == 1:
self.instruction_pointer = self.labels[args[0]]
def command_jl(self, args):
if self.stack.pop() == -1:
self.instruction_pointer = self.labels[args[0]]
def command_jz(self, args):
if self.stack.pop() == 0:
self.instruction_pointer = self.labels[args[0]]
def command_jnz(self, args):
if self.stack.pop() != 0:
self.instruction_pointer = self.labels[args[0]]
def command_cmp(self, args):
b, a = self.stack.pop(), self.stack.pop()
self.stack.append((a > b) - (a < b))
def command_mov(self, args):
self.registers[args[0]] = self.stack[-1]
def command_nop(self, args):
pass
def command_halt(self, args):
pass
def command_label(self, args):
pass
def run(self):
for _ in range(20000):
if self.instruction_pointer >= len(self.program):
break
command_string = self.program[self.instruction_pointer]
command, args = self.parse_command(command_string)
self.execute_command(command, args)
위와 같이 아름답게 코드를 고쳐 주십니다.
그래서 나온 최종 버전은 아래에 있습니다.
https://github.com/chobocho/simple_vm
결론:
1) 웬만하면 구글링 해서 open source 를 쓰자.
2) ChatGPT-4도 완전한 코드를 짜주지는 않는다 (디버깅은 필수)
'Coding > Python 삽질기' 카테고리의 다른 글
[Python] PyTorch 설치 (0) | 2023.04.05 |
---|---|
[ChatGPT에게 묻다] python으로 Simple Stack VM 만들기 (2) (0) | 2023.03.17 |
[ChatGPT에게 묻다] python으로 Simple Stack VM 만들기 (1) (0) | 2023.03.17 |
